Description
Specifications
| Specification | Description |
|---|---|
| Brand | Forney |
| Country of Origin | Imported |
| Amperage Input at Rated Output (230V) AC | 200A |
| Amperage Input at Rated Output (230V) DC | 32A |
| Amperage Input at Rated Output (KVA) AC | 7.36A |
| Amperage Input at Rated Output (KVA) DC | 7.36A |
| Amperage Input at Rated Output (KW) AC | 7.36A |
| Amperage Input at Rated Output (KW) DC | 7.36A |
| Clamp Cable Length | 15 ft. |
| Compatible Metal | Stainless Steel, Steel |
| Maximum Input Amperage | 200A |
| Maximum Open Circuit Voltage | 88V |
| Maximum Steel Thickness | 1/2 in. |
| Maximum Welding Amperage | 200A |
| Maximum Wire Diameter | 5/32 in. |
| Minimum Generator Power Required | 10,000W |
| Minimum Welding Amperage | 10A |
| Power Cord Length | 15 ft. |
| Product Height | 15.5 in. |
| Product Length | 23.25 in. |
| Product Weight | 80 lb. |
| Product Width | 10.375 in. |
| Rated Output at 20Percentage Duty Cycle – 16 VAC | 200A |
| Rated Output at 20Percentage Duty Cycle – 16 VDC | 200A |
| Torch Length | 15 ft. |
| Warranty | 3 Year |
| Work Cable Length | 15 ft. |
